| Place of Origin: | Langfang, Hebei, China |
|---|---|
| Brand Name: | Airt Industrial Products |
| Certification: | iso-9001 |
| Model Number: | Airt-KM-4001 |
| Minimum Order Quantity: | 1000 square |
| Price: | bargain |
| Packaging Details: | Waterproof plastic packaging |
| Delivery Time: | 7-15 work days |
| Supply Ability: | one day 2000 pieces |
| Project Solution Capability:: | Graphic Design, Total Solution For Projects, Cross Categori | Identity: | Manufacturer |
|---|---|---|---|
| Material: | Polyurethane, Nonmetal | Color: | Yellow |
| Place Of Origin: | Tianjin/Dacheng, China | Thickness: | 150mm |
| Raw Material: | Fiber Glass | Fire Performance: | Euro Class A1 |
| Application: | Warehouse | Type: | Glass Wool Products |
| Product Name: | High Temperature Glass Wool Roll | Density: | 12kg/m3 |
| Length: | Cusomized | Width: | 1200mm |
| Thermal Conductivity:: | 0.037W/mk | ||
| Highlight: | Yellow Glass Wool Sandwich Panel,Fireproof Glass Wool Sandwich Panel,Multipurpose Glasswool Insulation Batts |
||
| Product Code | Density (kg/m³) |
Thickness (mm) |
Width (mm) |
Conductivty (W/m·K) |
R-Value (m2/m·W) |
Packing (pcs/PKG) |
PKG/40'HQ (No#) |
|
| Airt HIBR 1250 | 12 | 50 | 1200 | 0.037 | 1.35 | 1 |
Loading Qty, Please consult |
|
| Airt HIBR 1275 | 12 | 75 | 1200 | 0.037 | 2.02 | 1 | ||
| Airt HIBR 12100 | 12 | 100 | 1200 | 0.037 | 2.70 | 1 | ||
| Airt HIBR 12150 | 12 | 150 | 1200 | 0.037 | 4.00 | 1 | ||
| Airt HIBR 12200 | 12 | 200 | 1200 | 0.035 | 5.50 | 1 | ||
| Airt HIBR 1650 | 16 | 50 | 1200 | 0.035 | 1.42 | 1 | ||
| Airt HIBR 1675 | 16 | 75 | 1200 | 0.035 | 2.14 | 1 | ||
| Airt HIBR 16100 | 16 | 100 | 1200 | 0.035 | 2.85 | 1 | ||
| Airt HIBR 2450 | 24 | 50 | 1200 | 0.033 | 1.50 | 1 | ||
| Airt HIBR 2475 | 24 | 75 | 1200 | 0.033 | 2.25 | 1 | ||
| Airt HIBR 24100 | 24 | 100 | 1200 | 0.033 | 3.00 | 1 |
Conductivity Value tested under temperature in 23°C
Consult your local sales representative for other available sizes and specification.
| Tested Content | Tested Method | Tested Value | |
| Density | ASTM C612 | 16kgs/m³ | |
| Thickness | GB/T 17795-2008 | 50mm | |
| Average diameter of fibers | GB/T 17795-2008 | 6.8μm | |
| Coefficient of Heat Conductivity | EN12667 | 0.038W/m·K | |
| Thermal Resistance | ASTM C653 | 1.30m²·K/W | |
| Average NRC | EN ISO 354 | 1.00 | |
| Maximum Service Temperature | ASTM C411 | 170°C | |
| Corrosion Resistance | ASTM C665 | NO Chemical Reaction | |
| Mold Resistance | ASTM C665 | Mildew proof | |
| Moisture Absorption | ASTM C1104 | Less 3% by weight | |
| Humidity veneration Rate | ASTM E96 | Max 0.013g/24Hours·m² | |
| Non-Combustibility | ASTM E84 | Flame Propagation: 25; Flame Diffustivity: 50 |
| Keep Cool | Keep Warm | Fire Proof | Moisture Proof | Noise Control | Sustainbility | Save Cost | Health Safe |
Thermal insulation used in electric power, chemical industry, light industry, petroleum, etc
 |
 |
 |
|
